SPECIFICATIONS
|
Mux
|
Demux
|
Mux
|
Demux
|
|
Center Wavelength(nm)
|
Customer Specify
|
|
Center Wavelength accuracy
(nm)
|
≦± 1.0
|
≦± 1.0
|
|
Channel Spacing(nm)
|
20
|
20
|
|
No. of Channel
|
1×8
|
1×4
|
|
Channel Passband
(-0.5dB Bandwidth) (nm)
|
≧12
|
≧12
|
|
Insertion Loss(dB)
|
≦4.5
|
≦3.0
|
|
Uniformity (dB)
|
≦1.5
|
≦1.0
|
|
Adjacent Channel Isolation
(dB)
|
≧15 ≧35
|
≧15 ≧35
|
|
Non-adjacent Channel
Isoation (dB)
|
N/A ≧40
|
N/A ≧40
|
|
Insertion Loss Temperature
Sensitivity (dB/℃)
|
≦0.005
|
≦0.005
|
|
Wavelength Temperature
Sensitivity (nm/℃)
|
≦0.005
|
≦0.005
|
|
Reture Loss (dB)
|
≧45
|
≧45
|
|
Directivity (dB)
|
≧55
|
≧55
|
|
Polartization Dispersion
Loss (PDL) (dB)
|
≦0.1
|
≦0.1
|
|
Operating Temperature (℃)
|
-20 to +70
|
|
Storage Temperature (℃)
|
-40 to +85
|
|
Package Dimension (mm)
|
125(L) × 90(W) ×
8(H)
|
100(L) × 80(W) ×
8(H)
|
|
Values
are referenced without connector(s)
|
