SPECIFICATIONS

Parameters

Multiplexer

Demultiplexer

Channel Spacing(nm)

10

20

10

20

Number of Channels

2

4

2

4

2

4

2

4

Available Channel

Wavelength Range (nm)

1300 ~ 1650

Effective Passband

Window (nm)

± 1.0

± 2.0

± 1.0

± 2.0

Max. Insertion Loss (dB)

≦0.6

≦1.2

≦0.6

≦1.2

≦1.4

≦2.4

≦1.2

≦2.0

Min. Non-Adjacent

Crosstalk (dB)

N/A

≧12

N/A

≧12

N/A

≧28

N/A

≧28

Min. Adjacent

Crosstalk (dB)

≧12

≧28

Max. PDL (dB)

≦0.2

≦0.2

≦0.2

≦0.2

≦0.2

≦0.3

≦0.2

≦0.3

Thermal Wavelength

Drift (pm/℃)

4 ( typical )

Operating Temperature(℃)

-20 to +70

Storage Temperature(℃)

-40 to +85

Fiber Type

SMF 28

Max. Optical Power (mW)

300

Dimension (mm)

65(L) × 3.0(D)(2ch) ; 140(L) × 90(W) × 11.5(H)(4ch)

Values are referenced without connector(s)
