| Introduction of products | |||||||
| 1 | 名�� | VD-201一片式螺��濶流量球𩺰（��吣型） | 1 | NAME | VD-201 1PC Reduced bore ball valve,Threaded end (ECONOMIC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 濶流量、防鏠�z���y | CHARACTER | Antistatic Device | ||||
| 2 | 名�� | VD-202一片式螺��濶流量球𩺰（PED 97/23/EC） | 2 | NAME | VD-202 1PC Reduced bore ball valve, Threaded end （PED 97/23/EC） | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| 操作方式 | 手把 挂𨶙 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| �C构�c度 | DIN 3202-M3 | OPERATING SYSTEM | Wrench、Lock???manual( with lock device available) | ||||
| 功能特性 | 濶流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device ??? (blow-out-proof) | ||||
| 3 | 名�� | VD-401 二片式螺�ォ𨻙y量球𩺰（工�珓活^ | 3 | NAME | VD-401 2PCS Full bore ball valve, Threaded end (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| ���I依据 | EN12266-1 | SHELL THICKNESS | EN 12516-1 | ||||
| �C构�c度 | DIN 3202-M3 | TEST | EN12266-1 | ||||
| 壁厚 | EN 12516-1 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| 4 | 名�� | VD-402 二片式螺�ォ𨻙y量球𩺰（��吣型） | 4 | NAME | VD-402 2PCS Full bore ball valve, Threaded end（ECONOMIC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | SS316 | ||||
| 中�l | SS316 | STEM | PTFE/RTFE | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 API 598 | TEST | EN12266-1 API 598 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench、 | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| 5 | 名�� | VD-601 二片式螺�ォ𨻙y量球𩺰 | 5 | NAME | VD-601 2PCS Full bore ball valve, Threaded end (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 密封件 | PTFE/RTFE | BALL | PTFE/RTFE | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | SEAT | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| 操作方式 | 手把 𩺰架 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| �C构�c度 | DIN 3202-M3 | OPERATING SYSTEM | Wrench、Bracket | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| 6 | 名�� | VD-602 二片式螺�ォ𨻙y量球𩺰（��吣型） | 6 | NAME | VD-602 2PCS Full bore ball valve,Threaded end（ECONOMIC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 API 598 | TEST | EN12266-1 API 598 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| 操作方式 | 手把 挂𨶙 𩺰架 | OPERATING SYSTEM | Wrench、Lock、Bracket | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| 7 | 名�� | VD-603 二片式螺�ォ𨻙y量球𩺰（PED 97/23/EC） | 7 | NAME | VS-603 2PCS Full bore ball valve, Threaded end(PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| 操作方式 | 手把 挂𨶙 𩺰架 | OPERATING SYSTEM | Wrench、Lock、Bracket | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| 8 | 名�� | VD-603MF 二片式�X外螺�ォ𨻙y量球𩺰（PED 97/23/EC） | 8 | NAME | VS-603MF 2PCS Full bore ball valve, Threaded end(PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | Working Pressure（CWP） | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| �X螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | FEMALE SCREW | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 外螺�エ凭� | 符合ISO7-1 | MALE SCREW | ISO7-1 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN 3202-M3 | ||||
| 操作方式 | 手把 挂𨶙 𩺰架 | OPERATING SYSTEM | Wrench、Lock、Bracket | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| 9 | 名�� | VD-604二片式螺�ォ𨻙y量球𩺰（ PED 97/23/EC） | 9 | NAME | VD-604 2PCS Full bore ball valve, Threaded end(PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂--1＂2000PSI 1-1/4＂--2＂1500PSI PN140/PN100 | CWP | 1/4＂--1＂2000PSI 1-1/4＂--2＂1500PSI PN140/PN100 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| 操作方式 | 手把 挂𨶙 𩺰架 | FACE TO FACE LENGTH | DIN 3202/M3 | ||||
| �C构�c度 | DIN3202/M3 | OPERATING SYSTEM | Wrench、Lock、Bracket | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-501T 三片式螺�ォ𨻙y量球𩺰（工�珓活^ | # | NAME | VD-501T 3PCS Full bore ball valve, Threaded end (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-501B 三片式�螻k口全流量球𩺰（工�珓活^ | # | NAME | VD-501B 3PCS Full bore ball valve, Butt welding (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 端口型式 | �螻k | END TYPE | Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | CAP | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | SEAT | PTFE/RTFE | ||||
| 密封件 | PTFE/RTFE | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-S3 | FACE TO FACE LENGTH | DIN3202-S3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-501S 三片式套焊全流量球𩺰（工�珓活^ | # | NAME | VD-501S 3PCS Full bore ball valve, Socket welding (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 端口型式 | 套焊 | END TYPE | Socket-Welding | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | SEAT | PTFE/RTFE | ||||
| 密封件 | PTFE/RTFE | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-501F 三片式法橃全流量球𩺰（工�珓活^ | # | NAME | VD-501F 3PCS Full bore ball valve, Flange end (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 端口型式 | 法橃 | END TYPE | FN40 Flanged | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | SEAT | PTFE/RTFE | ||||
| 密封件 | PTFE/RTFE | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-501LB 三片式加�c�螻k口全流量球𩺰（工�珓活^ | # | NAME | VD-501LB 3PCS Full bore ball valve, butt welding,long pattern (STANDARD) | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 端口型式 | 加�c�螻k | END TYPE | Long pattern Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | CAP | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | SEAT | SS316 | ||||
| 密封件 | PTFE/RTFE | STEM | PTFE/RTFE | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-S3 | FACE TO FACE LENGTH | DIN3202-S3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrentch | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-501C 三片式卡箍式全流量㇎生�侘y𩺰 | # | NAME | VD-501C 3PCS Sanitary full bore ball valve | ||
| 工作𢫦力 | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | CWP | 1/4＂－２＂1500PSI/PN100 2-1/2＂－4＂1000PSI/PN63 | ||||
| 端口型式 | 卡箍式 | END TYPE | Tri-Clamp END | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE | SEAT | PTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-1 | STANDARD | DESIGN | EN 12516-1 | ||
| 壁厚 | EN 12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-S3 | FACE TO FACE LENGTH | DIN3202-S3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y、�X孔全陻光 | CHARACTER | Anti-detonation Device, All inside surface be polished | ||||
| # | 名�� | VD-502T 三片式螺�ォ𨻙y量球𩺰（��吣型） | # | NAME | VD-502T 3PCS Full bore ball valve, Threaded end（ECONOMIC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN 3202-M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench、Lock | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-502B 三片式�螻k口全流量球𩺰（��吣型） | # | NAME | VD-502B 3PCS Full bore ball valve,Butt welding（ECONOMIC） | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | �螻k | END TYPE | Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | CAP | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-S13 | FACE TO FACE LENGTH | DIN3202-S13 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench, Lock | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-502S三片式套焊全流量球𩺰（��吣型） | # | NAME | VD-502S 3PCS Full bore ball valve, Socket welding（ECONOMIC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | 套焊 | END TYPE | Socket welding | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN 12516-2 | STANDARD | DESIGN | EN 12516-2 | ||
| 壁厚 | EN 12516-2 | SHELL THICKNESS | EN 12516-2 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202-M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| # | 名�� | VD-503T三片式全流量螺���盛結y𩺰�d （PED 97/23/EC） | # | NAME | VD-503T 3PCS Full bore ball valve, Threaded end (PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| �C构�c度 | DIN3202/M3 | TEST | DIN3202/M3 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | EN12266-1 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench, Lock | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic and Anti-detonation Device | ||||
| # | 名�� | VD-503B三片式�螻k口全流量球𩺰（PED 97/23/EC) | # | NAME | VD-503B 3PCS Full bore ball valve, Butt welding(PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | �螻k | END TYPE | Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | CF3M | CAP | CF3M | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 中�l | SS316 | SEAT | PTFE/RTFE | ||||
| 密封件 | PTFE/RTFE | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| �C构�c度 | DIN3202/S13 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/S13 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench、Lock | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-503F 三片式全流量法橃�盛結y𩺰（PED 97/23/EC) | # | NAME | VD-503F 3PCS Full bore ball valve, Flange end ( PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | 法橃 | END TYPE | Flange end | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| 𦧲接型式 | EN1092-1（21）RF/SF PN40 | END TYPE | EN1092-1（21）RF/SF PN40 | ||||
| �C构�c度 | DIN3202/F1 EN 558-1/F1 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/F1 EN 558-1/F1 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench、Lock | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-521T 三片式平台式螺�ォ𨻙y量球𩺰（ISO5211） | # | NAME | VD-521T 3PCS Full bore ball valve,Threaded end,ISO top for direct mount(ISO 5211) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 Threaded. | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方型SS316 | STEM | SS316 | ||||
| “O”型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�匟� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| �C构�c度 | DIN3202/M3 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 直接加�E控制器不�E把手 | OPERATING SYSTEM | Fix actuator without wrench | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-521F 三片式平台式法橃全流量球𩺰（ISO5211） | # | NAME | VD-521F 3PCS Full bore ball valve,Flange end,ISO top for direct mount(ISO 5211) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 端口型式 | 法橃 | END TYPE | Flange end, With ISO 5211 Direct Mounting | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方型SS316 | STEM | SS316 | ||||
| “O”型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�匟� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN 12516-1 | ||||
| �C构�c度 | DIN3202/F1 EN 558-1 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/F1 EN 558-1 | ||||
| 操作方式 | 直接加�E控制器不�E把手 | OPERATING SYSTEM | Fix actuator without wrench | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-541B三片平台式�螻k口全流量𩺰�d （ISO5211）（PED 97/23/EC）德���𢒑Q | # | NAME | VD-541B 3PCS Full bore ball valve,butt welding,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | �螻k | END TYPE | Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | CAP | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方形SS316 | STEM | SS316 | ||||
| 碟型�匟� | SS304 | FERRULE RING | VITON | ||||
| “O”型唨 | 氟橡𠃊 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| �C构�c度 | DIN3202/F1 EN 558-1 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/F1 EN 558-1 | ||||
| 操作方式 | 把手、挂𨶙、加�E控制器 | OPERATING SYSTEM | with Wrench and Lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-551T三片式平台式全流量螺���盛結y𩺰�d （ISO5211）（PED 97/23/EC） | # | NAME | VD-551T 3PCS Full bore ball valve,Threaded end,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方中�lSS316 | STEM | SS316 | ||||
| O型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�氻� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | ANSI B16.34 Class 300 | SHELL THICKNESS | ANSI B16.34 Class 300 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202/M3 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把、挂𨶙、可加�E控制器不�E把手 | OPERATING SYSTEM | with Wrench and Lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-551B三片平台式�螻k口全流量�盛結y𩺰（ISO5211）（PED 97/23/EC) | # | NAME | VD-551B 3PCS Full bore ball valve,butt welding,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | �螻k | END TYPE | Butt-welding | ||||
| 主要配件材í | 𩺰体 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | BODY | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰䳢 | CF3M | CAP | CF3M | ||||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方中�lSS316 | STEM | SS316 | ||||
| O型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�氻� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516 | STANDARD | DESIGN | EN12516 | ||
| 壁厚 | ANSI B16.34 Class 300 | SHELL THICKNESS | ANSI B16.34 Class 300 | ||||
| �C构�c度 | DIN3202/M3 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把、挂𨶙、可加�E控制器不�E把手 | OPERATING SYSTEM | with Wrench and Lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-551S 三片式平台式全流量套焊球𩺰（ISO5211）（PED 97/23/EC) | # | NAME | VD-551S 3PCS Full bore ball valve,Socket welding,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | 套焊 | END TYPE | Socket welding | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方中�lSS316 | STEM | SS316 | ||||
| O型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�氻� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516 | STANDARD | DESIGN | EN12516 | ||
| 壁厚 | ANSI B16.34 Class 300 | SHELL THICKNESS | ANSI B16.34 Class 300 | ||||
| �C构�c度 | DIN3202/M3 | TEST | EN12266-1 | ||||
| ���I依据 | EN12266-1 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把、挂𨶙、可直接加�E控制器不�E把手 | OPERATING SYSTEM | With wrench and lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-551F 三片式平台式全流量法橃�盛結y𩺰（ISO5211）（PED 97/23/EC) | # | NAME | VD-551F 3PCS Full bore ball valve,Flange end,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－4＂800PSI/PN40 | ||||
| 端口型式 | Flanged, With ISO5211 Direct Mounting | END TYPE | Flanged, With ISO5211 Direct Mounting | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方中�lSS316 | STEM | SS316 | ||||
| O型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�氻� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516 | STANDARD | DESIGN | EN12516 | ||
| 壁厚 | ANSI B16.34 Class 300 | SHELL THICKNESS | ANSI B16.34 Class 300 | ||||
| �C构�c度 | EN 558-1/F1 DIN3202/F1 | FACE TO FACE LENGTH | EN 558-1/F1 DIN3202/F1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| 操作方式 | 手把、挂𨶙、可直接加�E控制器不�E把手 | OPERATING SYSTEM | With wrench and lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-605 二片式平台式螺�ォ𨻙y量球𩺰（ISO5211）（PED 97/23/EC） | # | NAME | VD-605T 2PCS Full bore ball valve,Threaded end,With ISO top for direct mount(ISO5211, PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 2-1/2＂－3＂800PSI/PN40 | CWP | 1/4＂－２＂1000PSI/PN63 2-1/2＂－3＂800PSI/PN40 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | 四方中�lSS316 | STEM | SS316 | ||||
| O型唨 | 氟橡𠃊 | FERRULE RING | VITON | ||||
| 碟型�氻� | SS304 | PLUNGER WITH SPRING | SS304 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202/M3 | FACE TO FACE LENGTH | DIN3202-M3 | ||||
| 操作方式 | 手把、挂𨶙、可直接加�E控制器不�E把手 | OPERATING SYSTEM | With wrench and Lock,or fix actuator | ||||
| 功能特性 | 全流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-302L三通L式�嵾蒗y量球𩺰 | # | NAME | VD-302L 3WAY Reduced L-PORT ball valve, Threaded end (PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 螺�エ凭� | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202/M3 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench、Lock | ||||
| 功能特性 | 濶流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-302T 三通T式�嵾蒗y量球𩺰 | # | NAME | VD-302T 3WAY Reduced T-PORT ball valve,Threaded end(PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂－２＂1000PSI/PN63 | CWP | 1/4＂－２＂1000PSI/PN63 | ||||
| 端口型式 | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| 酒瓶䳢 | SS304 | CROWN WASHER | SS304 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202/M3 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把 挂𨶙 | OPERATING SYSTEM | Wrench、Lock | ||||
| 功能特性 | 濶流量、中�l防爆���y、防鏠�z���y | CHARACTER | Antistatic And Anti-detonation Device | ||||
| # | 名�� | VD-311三通L式全流量球𩺰 | # | NAME | VD-311 3WAY L-PORT Full bore ball valve, Threaded end (PED 97/23/EC) | ||
| 工作𢫦力 | 1/4＂1000PSI/PN63 | CWP | 1/4＂1000PSI/PN63 | ||||
| 端口型式 | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | END TYPE | DIN 259/DIN2999/ANSI B1.20.1（NPT）/PT/BSP/ISO 228 | ||||
| 主要配件材í | 𩺰体、𩺰䳢 | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | MATERIALS | SHELL | ASTM A-351 Gr.CF8M/EN 1.4408/SS316 | ||
| 𩺰球 | ASTM A-351 Gr.CF8M/SS316 | BALL | ASTM A-351 Gr.CF8M/SS316 | ||||
| 密封件 | PTFE/RTFE | SEAT | PTFE/RTFE | ||||
| 中�l | SS316 | STEM | SS316 | ||||
| �~范依据 | ���y依据 | EN12516-1 | STANDARD | DESIGN | EN12516-1 | ||
| 壁厚 | EN12516-1 | SHELL THICKNESS | EN12516-1 | ||||
| ���I依据 | EN12266-1 | TEST | EN12266-1 | ||||
| �C构�c度 | DIN3202/M3 | FACE TO FACE LENGTH | DIN3202/M3 | ||||
| 操作方式 | 手把 | OPERATING SYSTEM | Wrench | ||||
| 功能特性 | 全流量、中�l防爆���y | CHARACTER | Anti-detonation Device | ||||
| 以上所有�~格工作㗖度：-34℃----204℃（-30℉----400℉） | WORKING TEMPRETURE:-34℃----204℃（-30℉----400℉） | ||||||
